Mission Critical Scale Out Storage, Erasure coding, RAID Protect, All NVMe Support
Supermicro delivers significant benefits to Software Defined Storage Solutions:
Maximum Efficiency – High capacity 1U-4U form factors. Leading the industry with up 95% efficient Platinum level power supplies
Maximum Performance and expandability – All NVMe support with hybrid expander and delivering up to 20 GB/s throughput
Mission Critical Reliability – Capable of fully redundant and fault-tolerant operation with supplies, fans and redundant serverboards with remote management
Proven Compatibility – Lab validated hardware configurations optimized for high duty cycles workloads
Gerne beraten wir Sie bei einem persönlichem Beratungsgespräch oder telefonisch zu ihrem Vorhaben.
SYS-4029GP-TRT
- 3D Rendering
- Astrophysics Simulation
- Chemistry Simulation
- Virtualization
- Cloud Computing
- Research Laboratory/National Laboratory
Intel
4 HE
2 CPUs
24 DIMMs
24 Drives
8 GPUs
2 x 10 GbE
Red. PSU
SAS (native)
Key Features:
Dual Root System for balanced
performance & higher CPU
to GPU communication
Dual Socket P (LGA 3647) support
2nd Gen Intel® Xeon® Scalable
processors (Cascade Lake/Skylake)
24 DIMMs; up to 6TB 3DS ECC DDR4-2933MHz
8 PCI-E 3.0 x16 slots
(support up to 8 double width GPU),
2 PCI-E 3.0 x8, 1 PCI-E 3.0 x4
Up to 24 Hot-swap 2.5" drive bays;
8x 2.5" SATA drives supported
with included H/W, 2x 2.5" NVMe
drives supported with included H/W,
1 NVMe based M.2 SSD
2x 10GBase-T LAN ports via Intel C622
8 Hot-swap 92mm RPM cooling fans
2000W (2+2) Redundant Power
Supplies Titanium Level (96%+)
